ASTM F436M Washers
ASTM F436M type 1 is a standard material and dimensional specification for hardened steel washers, intended for general-purpose mechanical and structural use with bolts, nuts, studs, and other internally and externally threaded fasteners. Find chemical, mechanical and dimensional requirements for F436 type 1 hardened steel washers for use with fasteners having nominal thread diameters of 1/4 through 4 inch. Navnaagar Fastener are manufacturers and exproters & stocks full range of type 1 hardened steel washers to ASTM F436 specification.
Description
Standard: ASTM ASTM F436M
Material: 45# Steel, 50# Steel
Finish: Zinc Plain, H.D.G Phosphating, Black Plain, Galvanized
Hardness: HRC 38-45
Further, the F436 Material Grade washers can be used in combination with bolts like A449, A354, A193, A320, F1554 and whenever specified. These washers can either have a plain finish or can be hot dipped galvanized. The hardened flat ASTM F436 Washer is used under bolt nuts and head in order to increase the bearing area. It also offers hardness so that the bolt or the nut used can be rotated without the surface of the bearing being distorted.
Hardened Washers (ASTM F436M)
| Size No | I.D | O.D | THK MIN | THK MAX | Weight for KG / 1000 PCS |
|---|---|---|---|---|---|
| M12 | 14 | 27 | 4.6 | 3.1 | 11.69 |
| M14 | 16 | 30 | 4.6 | 3.1 | 14.21 |
| M16 | 18 | 34 | 4.6 | 3.1 | 18.29 |
| M20 | 22 | 42 | 4.6 | 3.4 | 29.64 |
| M22 | 24 | 44 | 4.6 | 3.4 | 31.51 |
| M24 | 26 | 50 | 4.6 | 3.4 | 42.68 |
| M27 | 30 | 56 | 4.6 | 3.4 | 52.14 |
| M30 | 33 | 60 | 4.6 | 3.4 | 58.62 |
| M33 | 36 | 66 | 4.6 | 3.4 | 71.82 |
| M36 | 39 | 72 | 4.6 | 3.4 | 86.36 |
| M39 | 42 | 78 | 4.6 | 3.4 | 102.23 |
| M42 | 45 | 84 | 7.2 | 4.6 | 175.25 |
| M45 | 48 | 90 | 7.2 | 4.6 | 202.52 |
| M48 | 52 | 95 | 7.2 | 4.6 | 220.93 |
| M52 | 58 | 104 | 8.7 | 6.1 | 309.92 |
| M56 | 62 | 107 | 8.7 | 6.1 | 334.13 |
| M64 | 70 | 118 | 8.7 | 6.1 | 397.48 |
| M72 | 78 | 130 | 8.7 | 6.1 | 475.97 |
| M80 | 86 | 142 | 8.7 | 6.1 | 562.57 |
| M90 | 96 | 159 | 8.7 | 6.1 | 710.57 |
| M100 | 107 | 176 | 8.7 | 6.1 | 866.05 |
